MSTMultiListCache Class Reference

A cache that uses multiple lists to maintain similarity/distance metrics to build a Minimum Spanning Tree (MST). More...

#include <MSTMultiListCache.h>

Inheritance diagram for MSTMultiListCache:

[legend]

Collaboration diagram for MSTMultiListCache:

[legend]

List of all members.

Public Member Functions
	MSTMultiListCache (const int totalESTCount, const int startOwnESTidx, const int numOwnESTs, const ESTAnalyzer *analyzer, const bool repopulateCaches, const int maxCachePerEST)
	The constructor.
virtual	~MSTMultiListCache ()
	The destructor.
virtual void	pruneCaches (const int estIdxAdded, std::vector< int > &repopulateList, const bool prefixListSize=true)
	Clear caches that contain entries for a newly added estIdx.
virtual void	mergeList (const int estIdx, const SMList &list)
	Merges a given SMList with current entries in the cache for a given EST.
void	getBestEntry (int &srcESTidx, int &destESTidx, float &metric, int &alignmentData, int &directionData) const
	Obtains the top-most similar entry from the MSTCache.
void	displayStats (std::ostream &os, const int MyRank) const
	Display cache usage statistics.
void	preprocess (SMList &list)
	Sort a Similarity Metric List (SMList) based on similarity metric and then prunes it.
Protected Member Functions
bool	pruneCache (SMList &list, const int estIdx)
	Helper method to prune a given SMList.
Private Attributes
std::vector< MSTCacheEntry >	cache
	The actual vector of cache entries for various nodes.
int	cacheRepopulation
	Number of times the cache needed to be repopulated.
int	prunedEntries
	Number of entries that were pruned from the cache.
long	analysisCount
	Number of times comparisons of ESTs were performed.

Detailed Description

A cache that uses multiple lists to maintain similarity/distance metrics to build a Minimum Spanning Tree (MST).

This class dervies off the MSTCache base class provides the functionality to manage a cache of similarity metrics using a collection of Lists. This cache is organized as follows: The cache is essentially a collection of SMList objects, one SMList for each EST (logically) owned by this cache. The lists are maintained in a sorted fashion with the best metrics at the top of the list to facilitate rapid construction of a Minimum Spanning Tree (MST).

Definition at line 70 of file MSTMultiListCache.h.

Constructor & Destructor Documentation

MSTMultiListCache::MSTMultiListCache	(	const int	totalESTCount,
		const int	startOwnESTidx,
		const int	numOwnESTs,
		const ESTAnalyzer *	analyzer,
		const bool	repopulateCaches,
		const int	maxCachePerEST
	)

The constructor.

This MST cache requires information about the number of ESTs in the system in order to effectively track the ESTs already added to the MST. These values must be passed in as the various parameters to this class. The constructor essentially passes off the parameters to the base class that saves the information (for future reference) in suitable instance variables.

Note:: This object is typically instantiated in the MSTClusterMaker::makeClusters() method.

Parameters:

`[in]`	totalESTCount	The total number of ESTs to be processed (that is, to be added to the MST).
`[in]`	startOwnESTidx	The starting index of the EST that is owned by the process that is using this cache. This value is used to internally normalize est index values to 0 for the first EST owned by this process.
`[in]`	numOwnESTs	The number of ESTs owned by the process that is using this cache. This information is used to reserve necessary space to hold SMLists for each EST owned by the manager/worker process.
`[in]`	analyzer	The analyzer to be used for EST comparisons, comparing metrics, and ordering entries in this cache depending on the type of EST analyzer (whether it is similarity based or distance metric based).
`[in]`	repopulateCaches	If this parameter is `true` then the MSTCache will request lists to be repopulated when needed. Repopulating lists guarantees that ultimately a MST will be developed. If repopulation is suppressed then the resulting spanning tree may not be a MST.
`[in]`	maxCachePerEST	This parameter suggests the maximum number of cached entries that must be maintained for a given EST. This parameter may not be really used by all dervied classes (this is only a suggestion).

Definition at line 43 of file MSTMultiListCache.cpp.

virtual MSTMultiListCache::~MSTMultiListCache ( ) [inline, virtual]

The destructor.

The instance variables in this class automatically manage all the memory associated this class. Consequently, the destructor does not have any special tasks to perform. It here present merely to adhere to coding conventions.

Definition at line 125 of file MSTMultiListCache.h.

Member Function Documentation

void MSTMultiListCache::displayStats	(	std::ostream &	os,
		const int	MyRank
	)			const `[virtual]`

Display cache usage statistics.

This method can be used to print the current cache usage statistics. This method prints the following information:

Number of ESTs cached by this cache.
Total number of SMEntries currently in the cache.
Average length of each list and the standard deviation.
The number of times the cache had to be repopulated.

Parameters:

`[out]`	os	The output stream to which statistics must be written.
`[in]`	MyRank	The MPI rank of the process to which this cache is assocaited. This information is used merely for displaying more informative statistics and does not influence the actual values displayed by this method.

Implements MSTCache.

Definition at line 223 of file MSTMultiListCache.cpp.

References analysisCount, cache, cacheRepopulation, and prunedEntries.

void MSTMultiListCache::getBestEntry	(	int &	srcESTidx,
		int &	destESTidx,
		float &	metric,
		int &	alignmentData,
		int &	directionData
	)			const `[virtual]`

Obtains the top-most similar entry from the MSTCache.

This method overrides the default implementation in the base class. It searches the analysis metrics stored in this cache for various ESTs to locate the best entry with the best metric. It populates the parameters with the appropriate value. Note that the parameters are initialized to -1, -1, and -1.0f respectively.

Parameters:

`[out]`	srcESTidx	The source EST index from where the similarity metric is being measured. The srcESTidx is already present in the MST.
`[out]`	destESTidx	The destination EST index that is the best choice to be added to the MST (based on the local information).
`[out]`	metric	The similarity/distance metric between the srcESTidx and the destESTidx.
`[out]`	alignmentData	The alignment data associated with the srcESTidx and the destESTidx.
`[out]`	directionData	The direction data associated with the srcESTidx and the destESTidx.

Implements MSTCache.

Definition at line 173 of file MSTMultiListCache.cpp.

References CachedESTInfo::alignmentData, MSTCache::analyzer, cache, ESTAnalyzer::compareMetrics(), CachedESTInfo::directionData, CachedESTInfo::estIdx, ESTAnalyzer::getInvalidMetric(), and CachedESTInfo::metric.

void MSTMultiListCache::mergeList	(	const int	estIdx,
		const SMList &	list
	)			`[virtual]`

Merges a given SMList with current entries in the cache for a given EST.

This method overrides the virtual method in the base class. As per the API requirement, it merges the given list with existing cache entries for the given EST such that only maxCachePerEST entries are retained in the cache. The retained entries are chosen so that they have the best metrics. Care is taken to ensure that the cache continues to remain sorted with the best metrics at the top of the cache.

Parameters:

`[in]`	estIdx	The index of the EST with which the given list must be merged.
`[in]`	list	The SMList to be merged with any existing entries in the cache for the given estIdx.

Implements MSTCache.

Definition at line 116 of file MSTMultiListCache.cpp.

References MSTCache::analyzer, ASSERT, cache, ESTAnalyzer::compareMetrics(), MSTCache::copy_n(), ESTAnalyzer::getInvalidMetric(), MSTCache::maxCachePerEST, and MSTCache::startOwnESTidx.

void MSTMultiListCache::preprocess ( SMList & list ) [virtual]

Sort a Similarity Metric List (SMList) based on similarity metric and then prunes it.

This method provides a convenient method for sorting a similarity metric list based on the similarity metric. This method simply uses the STL sort method with a suitable Functor for performing this task. Sorting is performed such that the highest similarity metric is first in the vector after sorting. Once sorting has been completed, this method ensures that the list is no longer than the specified cacheSize.

Parameters:

[in,out] list The SMList to be sorted based on the (similarity or distance) metric associated with each CachedESTInfo entry in the list.

Reimplemented from MSTCache.

Definition at line 204 of file MSTMultiListCache.cpp.

References analysisCount, MSTCache::analyzer, MSTCache::maxCachePerEST, and prunedEntries.

bool MSTMultiListCache::pruneCache	(	SMList &	list,
		const int	estIdx
	)			`[protected]`

Helper method to prune a given SMList.

This is a helper method that is called from the pruneCaches() method to remove all entries corresponding to the given estIdx.

Parameters:

`[in,out]`	list	The SMList whose entries needs to be pruned.
`[in]`	estIdx	The index of the EST whose entries must be removed from this list.

Returns:: This method returns true if the list becomes empty once all the entries have been removed.

Definition at line 97 of file MSTMultiListCache.cpp.

References prunedEntries.

Referenced by pruneCaches().

void MSTMultiListCache::pruneCaches	(	const int	estIdxAdded,
		std::vector< int > &	repopulateList,
		const bool	prefixListSize = `true`
	)			`[virtual]`

Clear caches that contain entries for a newly added estIdx.

This method overrides the virtual method in the base class and prunes entries corresponding to the estIdxAdded from the various lists maintained by this cache. The pruning operation is removes unused entries and facilitates repopulation of caches (if requested).

Parameters:

`[in]`	estIdxAdded	The index of the EST that has just been added to the MST.
`[out]`	repopulateList	The index values of ESTs whose cache needs to be repopulated. The list of EST indexes added to this list are only the ESTs that are owned by this process. If none of the caches need to be recomputed then this list is empty (all existing entries are removed).
`[in]`	prefixListSize	If this parameter is set to `true`, then the number of entries added to the repopulateList is inserted at the beginning of the vector. This eases transmission of lists via MPI to the master process.

Implements MSTCache.

Definition at line 57 of file MSTMultiListCache.cpp.

References cache, cacheRepopulation, MSTCache::nodesAdded, pruneCache(), and MSTCache::repopulateCaches.

Member Data Documentation

long MSTMultiListCache::analysisCount [private]

Number of times comparisons of ESTs were performed.

Tracks the number of times EST comparisons were performed. This instance variable is initialized to 0 (zero). The set of values sorted via teh sortAndPrune() method are used to track the number of comparisons performed and this instance variable is suitably adjusted.

Definition at line 305 of file MSTMultiListCache.h.

Referenced by displayStats(), and preprocess().

std::vector<MSTCacheEntry> MSTMultiListCache::cache [private]

The actual vector of cache entries for various nodes.

This cache contains the list of cache entries for each node owned and managed by this MSTCache. The list is initialized to have a set of empty lists in the constructor, when the cache is instantiated for use.

Definition at line 273 of file MSTMultiListCache.h.

Referenced by displayStats(), getBestEntry(), mergeList(), and pruneCaches().

int MSTMultiListCache::cacheRepopulation [private]

Number of times the cache needed to be repopulated.

This instance variable is used to track the number of times the cache had to be repopulated as one of the entries ran out of data. This variable is initialized to 0 (zero), incremented in the pruneCaches() method, and displayed in the displayStats() method.

Definition at line 283 of file MSTMultiListCache.h.

Referenced by displayStats(), and pruneCaches().

int MSTMultiListCache::prunedEntries [private]

Number of entries that were pruned from the cache.

This instance variable is used to track the number of entries that were pruned from the cache by the pruneCache() method. This value indicates the number of entries in the cache that were unused. Moreover, this value also a measure of the amount of unnecessary adjacency information calculation operations that were performed for this cache by all the processes put together.

Definition at line 295 of file MSTMultiListCache.h.

Referenced by displayStats(), preprocess(), and pruneCache().

The documentation for this class was generated from the following files:
